Power Divider

category:

Waveguide

Adapter Amplifier Attenuator Cable Assembly Circulator/Isolator Connector Detector Directional Coupler Filter Limiter MMIC Die Chip MMIC Module Power Divider Power Transistors Switch Termination VCO

product:

Power Amplifier Driver Amplifier Low Noise Amplifier Limiting LNA Bidirectional Amplifier Phase Shifter Digitally Attenuator Time Delayer VCA Microwave Switch Power Divider Limiter

Part Number	Start Freq. (GHz)	Stop Freq. (GHz)	I.L. (dB)	I.L. Flatness (dB)	Isolation (dB)	VSWRin	VSWRout	△A (dB)	△Ф (°)	Dimension (mm)	Package	Datasheet	RFQ
SGH104010020	1	2	2.2	±0.5	14	1.6	1.6	±0.5	±5	5.00x5.00x1.50	QFN Pads	N/A	RFQ
SGH104010020-1	1	2	2.2	±0.5	14	1.6	1.6	±0.5	±5	5.00x5.00x1.50	QFN Pads	N/A	RFQ
SGB7029H	2	12	1.5	±0.5	13	1.8	1.5	±0.3	±5	5.08x5.08x1.40	QFN Pads	N/A	RFQ
SGH9020H	8	12	0.9	±0.3	18	1.6	1.4	±0.3	±5	5.00x5.00x2.50	QFN Pads	N/A	RFQ
SGH9020HM	8	12	0.9	±0.3	18	1.6	1.4	±0.3	±5	5.00x5.00x2.50	QFN Pads	N/A	RFQ
SGH9008H	8	18	2	±0.6	15	1.5	1.3	±0.5	±10	4.00x4.00x1.10	QFN Pads	N/A	RFQ
SGH9007H	8	18	2	±0.6	15	1.5	1.5	±0.5	±10	4.00x4.00x1.10	QFN Pads	N/A	RFQ

Part Number	Start Freq. (GHz)	Stop Freq. (GHz)	I.L. (dB)	I.L. Flatness (dB)	Isolation (dB)	VSWRin	VSWRout	△A (dB)	△Ф (°)	Dimension (mm)	Package	Datasheet	RFQ
SGH104010020	1	2	2.2	±0.5	14	1.6	1.6	±0.5	±5	5.00x5.00x1.50	QFN Pads	N/A	RFQ
SGH104010020-1	1	2	2.2	±0.5	14	1.6	1.6	±0.5	±5	5.00x5.00x1.50	QFN Pads	N/A	RFQ
SGB7029H	2	12	1.5	±0.5	13	1.8	1.5	±0.3	±5	5.08x5.08x1.40	QFN Pads	N/A	RFQ
SGH9020H	8	12	0.9	±0.3	18	1.6	1.4	±0.3	±5	5.00x5.00x2.50	QFN Pads	N/A	RFQ
SGH9020HM	8	12	0.9	±0.3	18	1.6	1.4	±0.3	±5	5.00x5.00x2.50	QFN Pads	N/A	RFQ
SGH9008H	8	18	2	±0.6	15	1.5	1.3	±0.5	±10	4.00x4.00x1.10	QFN Pads	N/A	RFQ
SGH9007H	8	18	2	±0.6	15	1.5	1.5	±0.5	±10	4.00x4.00x1.10	QFN Pads	N/A	RFQ
