Inset Attenuator_RF Attenuator

category:

Adapter Amplifier Attenuator Cable Assembly Circulator/Isolator Connector Directional Coupler Filter Limiter MMIC Die Chip MMIC Module Power Divider Power Transistors Switch Termination VCO

product:

Coaxial Fixed Attenuator Step Variable Attenuator Inset Attenuator Low PIM Attenuator

Part Number	Average Power (W)	PeakPower (KW)	Low Freq. (GHz)	High Freq. (GHz)	VSWR	Nominal Attenuation Value (dB)	Connector Type	RFQ
SAT27B50XXXXN	50	10	DC	4	1.25-1.35	3,6,10,20,30,40	N	RFQ
SAT27B100XXXXN	100	10	DC	4	1.25-1.40	3,6,10,20,30,40	N	RFQ
SAT27B300XXXXN	300	10	DC	4	1.25-1.40	3,6,10,20,30,40	N	RFQ
SAT27B50XXXXWN	50	5	DC	10	1.20-1.35	10,20,30	N	RFQ
SAT27B50XXXXGN	50	5	DC	18	1.20-1.40	10,20,30,40	N	RFQ
SAT27B100XXXXWN	100	5	DC	10	1.25-1.40	20,30,40	N	RFQ
SAT27B200XXXXWN	200	5	DC	10	1.25-1.40	10,20,30,40	N	RFQ

Part Number	Average Power (W)	PeakPower (KW)	Low Freq. (GHz)	High Freq. (GHz)	VSWR	Nominal Attenuation Value (dB)	Connector Type	RFQ
SAT27B50XXXXN	50	10	DC	4	1.25-1.35	3,6,10,20,30,40	N	RFQ
SAT27B100XXXXN	100	10	DC	4	1.25-1.40	3,6,10,20,30,40	N	RFQ
SAT27B300XXXXN	300	10	DC	4	1.25-1.40	3,6,10,20,30,40	N	RFQ
SAT27B50XXXXWN	50	5	DC	10	1.20-1.35	10,20,30	N	RFQ
SAT27B50XXXXGN	50	5	DC	18	1.20-1.40	10,20,30,40	N	RFQ
SAT27B100XXXXWN	100	5	DC	10	1.25-1.40	20,30,40	N	RFQ
SAT27B200XXXXWN	200	5	DC	10	1.25-1.40	10,20,30,40	N	RFQ

Download the selection guide
