6-way splitter,Power Splitter,Power Divider

category:

Adapter Amplifier Attenuator Cable Assembly Circulator/Isolator Connector Directional Coupler Filter Limiter MMIC Die Chip MMIC Module Power Divider Power Transistors Switch Termination VCO

product:

2-way 3-way 4-way 5-way 6-way 8-way 10-way 12-way 16-way

Part Number	Low Freq. (GHz)	High Freq. (GHz)	Max.I.L.* (dB)	Isolation Min.(dB)	VSWRin Max.	VSWRout Max.	Amplitude Unbalance(±dB)	Phase Unbalance(±°)	Connector Type	Power (W)	RFQ
PD0606001800GA	6	18	1.8	16	1.80	1.50	0.7	8	SMA	20	RFQ
PD0604001800GA	4	18	2.2	16	1.80	1.50	0.7	8	SMA	20	RFQ
PD0602001800GA	2	18	2.2	16	1.80	1.50	0.7	8	SMA	20	RFQ
PD0602000800GA	2	8	1.4	18	1.40	1.30	0.4	6	SMA	30	RFQ
PD0602000400GA	2	4	1.0	20	1.40	1.30	0.4	6	SMA	30	RFQ
PD0601000800GA	1	8	1.8	18	1.40	1.30	0.4	5	SMA	30	RFQ
PD0601000400GA	1	4	1.5	20	1.40	1.30	0.4	5	SMA	30	RFQ
PD0600800250GN	0.8	2.5	0.8	20	1.30	1.25	0.5	5	N	100	RFQ
PD0600800250GA	0.8	2.5	1.2	20	1.40	1.25	0.5	8	SMA	30	RFQ
PD0606982700MN	0.698	2.7	1.0	18	1.50	1.30	0.6	6	N	50	RFQ
PD0600500200GA	0.5	2	1.5	20	1.40	1.30	0.4	5	SMA	30	RFQ

Part Number	Low Freq. (GHz)	High Freq. (GHz)	Max.I.L.* (dB)	Isolation Min.(dB)	VSWRin Max.	VSWRout Max.	Amplitude Unbalance(±dB)	Phase Unbalance(±°)	Connector Type	Power (W)	RFQ
PD0606001800GA	6	18	1.8	16	1.80	1.50	0.7	8	SMA	20	RFQ
PD0604001800GA	4	18	2.2	16	1.80	1.50	0.7	8	SMA	20	RFQ
PD0602001800GA	2	18	2.2	16	1.80	1.50	0.7	8	SMA	20	RFQ
PD0602000800GA	2	8	1.4	18	1.40	1.30	0.4	6	SMA	30	RFQ
PD0602000400GA	2	4	1.0	20	1.40	1.30	0.4	6	SMA	30	RFQ
PD0601000800GA	1	8	1.8	18	1.40	1.30	0.4	5	SMA	30	RFQ
PD0601000400GA	1	4	1.5	20	1.40	1.30	0.4	5	SMA	30	RFQ
PD0600800250GN	0.8	2.5	0.8	20	1.30	1.25	0.5	5	N	100	RFQ
PD0600800250GA	0.8	2.5	1.2	20	1.40	1.25	0.5	8	SMA	30	RFQ
PD0606982700MN	0.698	2.7	1.0	18	1.50	1.30	0.6	6	N	50	RFQ
PD0600500200GA	0.5	2	1.5	20	1.40	1.30	0.4	5	SMA	30	RFQ

*Insertion Loss excludes split loss.
